Why Screw Pull-Out Strength Matters in Trauma Fixation

In fracture surgery, Trauma Implants may look perfectly positioned on an X-ray, yet fixation can still be compromised if the screws cannot maintain sufficient purchase in bone. This is especially important in osteoporotic metaphyseal bone, comminuted fractures, and constructs exposed to repeated loading during rehabilitation. For surgeons, distributors, and implant developers evaluating screw pull-out strength in trauma fixation, orthopedic bone screw pullout resistance, and bone screw fixation in osteoporotic bone, the real question is not simply “How strong is the screw?” It is whether the complete screw-bone interface can resist loss of fixation under the intended loading environment. Three terms are central to that discussion: axial pullout load, cortical purchase, and thread engagement.

What Is Screw Pull-Out Strength in Trauma Fixation?

Screw pull-out strength is the peak axial force required to extract an implanted screw from the material in which it is anchored. It is normally expressed in newtons (N). In laboratory testing, the screw is inserted into a defined substrate and then loaded along its axis until the surrounding material or screw-bone interface fails.

This parameter is sufficiently important that ASTM F543-23, Standard Specification and Test Methods for Metallic Medical Bone Screws, includes a dedicated Annex A3 for determining the axial pullout load of medical bone screws. The same standard also addresses torsional properties, driving torque and self-tapping performance, reflecting an important engineering reality: no single mechanical measurement completely describes screw performance. :contentReference[oaicite:0]{index=0}

For trauma fixation, pull-out strength is particularly relevant when screws help secure locking plates, conventional plates, fracture fragments or other internal fixation constructs. If the screw loses purchase, the consequences can include screw toggling, progressive loosening, loss of reduction and eventual construct failure. However, pull-out strength should be interpreted as one component of fracture fixation stability, not as a stand-alone prediction of clinical success.

Why Does Screw Pull-Out Strength Matter for Trauma Implants?

1. Pull-Out Resistance Helps Maintain Fracture Reduction

The immediate job of an internal fixation construct is to control fracture-fragment motion to the degree required by the chosen fixation strategy. A screw that loses anchorage cannot contribute as intended to plate fixation or interfragmentary compression.

AO Surgery Reference illustrates how fixation requirements depend on anatomy and loading. For distal-third humeral shaft plate fixation, AO describes using bicortical screws and typically seeking approximately six cortical holds proximal and distal to the fracture. In segmental radial fractures, AO recommends three bicortical screws in each main fragment because of the high torsional stresses. These are procedure-specific recommendations rather than universal screw-count rules, but they demonstrate why secure bicortical fixation and adequate cortical engagement matter at construct level. :contentReference[oaicite:1]{index=1}

2. Low Bone Density Can Make the Screw-Bone Interface the Weak Link

Implant metal may remain structurally intact while the surrounding bone fails. This is why bone mineral density, trabecular architecture and cortical thickness matter when assessing screw anchorage.

A controlled study using synthetic osteoporotic bone models provides a useful numerical example. With a 3.5 mm cortical screw, mean pull-out strength was 78.3 ± 7.0 N in a severe osteoporotic-density model of 80 mg/cm³ when a drilled pilot hole was used. In the 240 mg/cm³ model, the corresponding value was 477.5 ± 41.4 N. For the 4.0 mm cancellous screw tested in the same study, pull-out strength increased from 94.8 ± 4.5 N to 580.8 ± 14.7 N between those two density models. Statistical analysis found bone density had a significant effect on pull-out load (p < 0.001). These numbers should not be transferred directly to a patient, because they came from synthetic models, but they clearly demonstrate how strongly substrate quality can affect fixation. :contentReference[oaicite:2]{index=2}

This is one reason orthopedic screw fixation in osteoporotic bone cannot be optimized simply by selecting a screw that performs well in a high-density test block.

3. Pull-Out Strength Helps Evaluate Screw Geometry

The threads transfer load from the metal implant into bone. Their major diameter, pitch, depth, shape and engaged length therefore influence how much bone participates in resisting extraction.

In a classic biomechanical study by Chapman and colleagues involving 12 types of cancellous screws, experimentally measured pull-out force showed a strong relationship with predicted shear failure force (R² = 0.947). The model identified screw major diameter, thread engagement length, substrate shear strength and thread geometry as important variables. In that test system, tapping reduced pull-out force by an average of 8%, while tapping enlarged hole volume by an average of 27%. :contentReference[oaicite:3]{index=3}

The practical point is not that one thread pitch or tapping method should always be used. It is that bone screw thread design must be evaluated together with the target bone environment and surgical preparation technique.

Which Factors Have the Greatest Effect on Bone Screw Pull-Out Strength?

Bone Quality and Cortical Thickness

Bone density frequently has a larger effect than small modifications in screw geometry. In weak cancellous bone, threads have less material available to resist shear. In cortical fixation, cortical thickness influences both the amount of material engaged by the threads and the torque the bone can tolerate before stripping.

A 2020 cadaveric study of cortical screw insertion found a strong relationship between cortical thickness and experimentally measured stripping torque, with R² = 0.862. This supports the concept that local bone characteristics—not simply nominal screw diameter—help determine how much fixation can safely be generated. :contentReference[oaicite:4]{index=4}

Screw Diameter, Thread Depth and Thread Pitch

Increasing the amount of bone engaged by the threads can improve resistance, but “larger screw equals stronger fixation” is too simplistic.

Chapman's biomechanical work found pull-out behavior to be related to major diameter, engagement length, substrate strength and a thread shape factor incorporating thread depth and pitch. A separate mechanical study of headless screws reported pull-out forces ranging from 45.23 to 233.22 N among the tested designs and found that a smaller screw could outperform a larger one because more threads were engaged. :contentReference[oaicite:5]{index=5}

For implant evaluation, that means thread geometry, the number of engaged threads and available bone stock deserve attention alongside outside diameter.

Length of Thread Engagement

More effective engagement generally increases the volume of bone involved in resisting extraction. Chapman et al. identified engagement length as one of the parameters controlling pull-out force in porous material. :contentReference[oaicite:6]{index=6}

Depth should still be planned anatomically. Simply choosing a longer screw without considering the far cortex, joint surface, neurovascular structures or fracture geometry can introduce other risks.

Pilot-Hole Diameter

The pilot hole must provide a path for insertion without removing so much bone that thread purchase is compromised.

One human cadaver study compared 25 anatomically matched cancellous-bone sites prepared with 2.5 mm or 3.2 mm pilot holes for a 6.5 mm cancellous screw. Mean pull-out strength was 360.6 N with the 2.5 mm pilot hole and 313.5 N with the 3.2 mm hole, a mean difference of 47.1 N; the overall comparison reached statistical significance at p = 0.047. Importantly, one of the four anatomical locations showed the opposite trend, so these findings should not be converted into a universal recommendation to under-drill every screw hole. :contentReference[oaicite:7]{index=7}

Insertion Torque and Screw-Hole Stripping

A common misconception is that tightening a screw harder automatically produces stronger fixation. Once the surrounding bone begins to strip, the opposite can occur.

In a study of cortical screw insertion into lamb and human bone, screws inserted with thread-damaging torque showed 40–50% lower holding strength than screws inserted at lower torque levels. :contentReference[oaicite:8]{index=8}

The consequences of actual stripping can be even larger. In a 2020 cadaveric study, stripped holes showed approximately a 95% reduction in normalized compression and a 93% reduction in normalized pull-out force compared with unstripped insertions. The same research found that compression increased as screws were tightened up to approximately 80% of predicted stripping torque, while further tightening produced no meaningful additional compression. :contentReference[oaicite:9]{index=9}

That makes stripping torque an important engineering and surgical consideration. Maximizing torque and optimizing fixation are not the same thing.

High Pull-Out Strength vs Poor Screw Purchase: What Changes?

Does a Higher Pull-Out Number Always Mean a Better Trauma Screw?

No. This distinction is important when evaluating trauma implant biomechanics.

Axial pull-out testing applies force along the long axis of the screw, whereas an implanted plate-and-screw construct experiences combinations of axial load, bending, torsion, shear and repeated cyclic loading. A biomechanical study examining thread designs specifically noted that pure axial pull-out does not reproduce most physiological loading conditions, even though it remains the standardized approach for evaluating screw anchorage. :contentReference[oaicite:10]{index=10}

Research on plate fixation has also shown that lateral migration resistance can affect construct stability independently of axial pull-out strength. In one study comparing different thread forms, the screw design with the greatest axial pull-out strength was not the same design that produced the greatest resistance to lateral migration. :contentReference[oaicite:11]{index=11}

For buyers and engineers, therefore, a laboratory value such as “500 N pull-out strength” means very little unless the test conditions are also known: substrate density, screw diameter, engagement depth, pilot-hole preparation, loading rate and applicable test method all matter.

Locking Screw vs Conventional Screw: How Does Pull-Out Failure Differ?

A conventional plate screw and a locking screw do not stabilize a construct in exactly the same way.

According to AO principles, a conventional screw draws the plate toward the bone, and fixation relies substantially on compression and friction between plate and bone. A locking screw, by contrast, engages the threaded plate hole and forms a fixed-angle construct. The screw, plate and bone therefore function more like a connected frame. :contentReference[oaicite:12]{index=12}

This angular stability can be valuable in osteoporotic or comminuted fractures, but it does not make the screw-bone interface irrelevant. Bone around the threaded portion still has to carry load. Locking constructs can also fail through screw-bone interface failure, plate deformation or other mechanisms depending on the anatomy and load.

The useful comparison is therefore:

Conventional fixation: secure screw purchase is needed to generate and maintain plate-to-bone compression.
Locking fixation: the threaded screw head provides angular stability at the plate, while the screw body still requires adequate bone anchorage.

How Should Trauma Implant Buyers Evaluate Screw Pull-Out Performance?

A procurement specification that asks only for “high pull-out strength” is incomplete. For meaningful comparison between suppliers or designs, request the conditions under which the number was obtained.

Ask for the Test Standard and Method

Confirm whether axial pull-out testing follows ASTM F543 or another defined protocol. ASTM F543-23 explicitly includes axial pullout testing as well as torsional, driving-torque and self-tapping test methods for metallic medical bone screws. :contentReference[oaicite:13]{index=13}

Ask What Test Material Was Used

Polyurethane foam provides controlled density and low sample-to-sample variation, making it useful for design comparison. Cadaveric bone better reflects biological heterogeneity but introduces greater variation. Results from different substrates should not be treated as directly interchangeable.

Compare Identical Test Conditions

For a useful supplier-to-supplier comparison, keep variables such as these consistent:

• Bone model or polyurethane density

• Screw outside and core diameter

• Thread pitch and thread depth

• Insertion depth and number of engaged threads

• Pilot-hole diameter

• Tapping or non-tapping preparation

• Axial loading rate

• Number of samples tested

• Mean, standard deviation and failure mode

Do Not Evaluate Pull-Out Load in Isolation

Depending on the intended orthopedic fixation system, buyers may also need information on torsional strength, insertion torque, stripping behavior, locking-head engagement, plate mechanical properties, cyclic loading and instrument compatibility.

This is particularly important because insertion torque and pull-out strength are not interchangeable. A Journal of Orthopaedic Trauma study using an osteoporotic cancellous-bone model found no significant correlation between maximum insertion torque and pull-out strength for the tested screw designs (p = 0.069, r = -0.37). :contentReference[oaicite:14]{index=14}

How Screw Pull-Out Strength Influences Trauma Fixation System Design

Strong fracture fixation is a system problem rather than a screw-only problem. The engineer has to consider the interaction between implant geometry, bone quality, drilling technique, screw placement, plate working length, number and distribution of screws, and the anticipated loading environment.

That is why clinically useful trauma systems are usually designed around compatible components instead of isolated screws. The current trauma portfolio from ATOM Medical Devices Co., Ltd. includes locking plates, cannulated screws, intramedullary fixation products and corresponding trauma instruments. ATOM's published product catalogue also lists region-specific locking plate categories for the wrist, foot and ankle, clavicle, humerus, ulna/radius, pelvis, femur, tibia and fibula. :contentReference[oaicite:15]{index=15}

For example, a screw selected for a distal humerus plate cannot be evaluated only by its theoretical axial extraction force. Screw trajectory, available cortical bone, plate-hole geometry, locking compatibility and surrounding anatomy all influence how the fixation behaves once the patient begins loading the limb.

What Does the Evidence Mean in Practice?

Several conclusions emerge consistently from biomechanical research:

• Bone quality matters. Lower-density bone substantially reduces screw anchorage in experimental models.

• Thread engagement matters. Major diameter, engagement length, thread depth and pitch influence how load is transferred into bone. :contentReference[oaicite:16]{index=16}

• Pilot-hole preparation matters. Removing excessive bone can weaken purchase, although the ideal preparation depends on screw design and bone type. :contentReference[oaicite:17]{index=17}

• More tightening is not automatically better. Once the screw hole strips, fixation strength can fall dramatically. :contentReference[oaicite:18]{index=18}

• Axial pull-out is not the entire clinical loading environment. Lateral migration, bending, torsion and cyclic loading also deserve consideration. :contentReference[oaicite:19]{index=19}

Conclusion: Pull-Out Strength Is a Key Metric, Not the Whole Fixation Story

Screw pull-out strength matters because the bone-screw interface is one of the load-transfer points that keeps a trauma fixation construct working. Poor anchorage can contribute to loosening and loss of stability, while appropriate bicortical purchase, sufficient thread engagement and controlled insertion torque help the screw perform as intended.

But the highest isolated pull-out value should never be treated as proof of the best trauma implant. Bone density, cortical thickness, screw geometry, pilot-hole preparation, plate configuration, construct stiffness, angular stability and cyclic loading all influence fixation. For manufacturers and procurement teams, the most useful comparison is therefore not “Which screw has the biggest number?” but “Under what standardized conditions was the screw tested, and how does that performance relate to the intended fixation system?”

Explore Trauma Fixation Solutions from ATOM Medical Devices Co., Ltd.

If you are evaluating trauma fixation screws for osteoporotic bone, locking plate and screw systems for fracture fixation, or orthopedic trauma implants with compatible surgical instruments, review the implant dimensions, compatible screws, instrumentation and available mechanical test documentation before making a procurement decision. ATOM Medical Devices Co., Ltd. provides trauma implant and instrument solutions covering locking plates, cannulated screws, intramedullary fixation and related surgical instrumentation. Contact the team to discuss the intended anatomical application, implant configuration and technical documentation required for your market or project. :contentReference[oaicite:20]{index=20}

FAQ About Screw Pull-Out Strength in Trauma Fixation

What is a good pull-out strength for an orthopedic bone screw?

There is no universal pull-out force that defines a “good” orthopedic screw. The measured value depends strongly on bone or test-block density, screw dimensions, thread design, engagement depth, pilot-hole preparation and testing protocol. A value should therefore be compared only with screws tested under equivalent conditions, preferably using a recognized method such as ASTM F543.

Does a larger bone screw always have greater pull-out strength?

No. Diameter is one factor, but thread pitch, thread depth, number of engaged threads, engagement length and substrate quality can change the result. Published biomechanical testing has even found instances where a smaller headless screw produced greater holding force than a larger design because of differences in thread engagement. :contentReference[oaicite:21]{index=21}

Why is screw pull-out strength important in osteoporotic fractures?

Osteoporotic bone provides less dense material for the screw threads to engage. Experimental studies have repeatedly shown that bone density strongly affects pull-out resistance. Consequently, fixation strategies for weak bone often consider screw distribution, locking technology, available cortical purchase and overall construct mechanics rather than relying on a conventional screw-bone interface alone. :contentReference[oaicite:22]{index=22}

Can tightening a screw harder improve its pull-out strength?

Not indefinitely. Excessive tightening can damage or strip the bone threads. One cadaveric study reported a 93% reduction in normalized pull-out force after screw-hole stripping, demonstrating why maximum possible torque is not the same as optimal fixation. :contentReference[oaicite:23]{index=23}

Does a locking screw eliminate the risk of screw pull-out?

No. Locking screws engage the threaded plate hole to create fixed-angle stability, which changes the mechanics compared with a conventional plate screw. However, the screw body still transfers forces into bone. Poor bone quality or inadequate anchorage can therefore remain relevant to construct failure. AO describes locking plate fixation as a rigid frame in which the screw is locked to both plate and bone rather than relying primarily on plate-bone friction. :contentReference[oaicite:24]{index=24}
