Material Excellence
Instruments are constructed from premium stainless steels (05Cr17Ni4Cu4Nb, 420B, 316L, 304), offering high fatigue resistance. Electropolished surfaces minimize tissue friction and surgical trauma.
Comprehensive Locking Plate Procedure Coverage
The set systematically covers the entire locking plate internal fixation workflow: from fracture fragment reduction, plate contouring, and precise positioning/drilling to bone thread preparation, screw implantation, and final torque locking. All instruments work synergistically to ensure seamless procedural transitions, meeting the demands for procedural completeness and efficiency in open reduction internal fixation, particularly compatible with 2.7mm and 3.5mm locking screw systems.
Precise Reduction and Anatomical Adaptation
The set provides specialized reduction and contouring tool combinations to ensure anatomical fracture reduction and ideal plate-to-bone contact. Bone levers facilitate exposure and initial manipulation, pointed reduction forceps achieve precise fragment alignment, and centralized bone holding forceps stabilize fracture ends while maintaining reduction. Dedicated left/right plate benders allow surgeons to perform precise three-dimensional contouring according to bone anatomy—a crucial prerequisite for achieving low-profile plate contact and stable fixation.
Modular Guidance System Ensures Precision Positioning and Drilling
The modular, multi-specification guided drilling system ensures accurate positioning and preparation of screw channels for different screw sizes (2.7mm cortical/locking screws, 3.5mm cortical/locking screws). Triangular and threaded guidewires provide initial positioning guidance. A series of dedicated bone drills (Ø2.0mm, Ø2.4mm, Ø2.8mm) combined with diverse guide sleeves (e.g., Ø2.7/Ø2.0 double-ended, 2.0mm universal double-ended, Ø3.5/Ø2.4 double-ended, Ø2.8mm) flexibly adapt to various screw hole requirements, ensuring drilling direction accuracy and bone channel quality even in complex anatomical locations.
Efficient Bone Thread Preparation and Depth Measurement
Dedicated taps for different screw types enable efficient, matched bone thread formation. Locking screw taps (HS2.7, HS3.5) are specifically designed for locking screws, while cortical bone taps (HA3.5) serve standard cortical screws. Depth gauges accurately measure prepared screw channel depth, providing reliable data for appropriate screw length selection—a critical step to prevent screw over-penetration through the opposite cortex or insufficient fixation strength from short screws.
Secure Screw Implantation and Precise Torque Control
The set provides reliable screw holding and driving tools, with particular emphasis on meeting the core torque precision requirements of locking technology. Large and small screw holding sleeves ensure stable screw passage and implantation. Comprehensive drivers and drive handles accommodate different operational preferences and scenarios. The core torque control system includes torque quick-change handles, standard torque handles, and torque quick-change adapters, ensuring locking screws are safely and reliably final-tightened according to strictly set torque values, preventing screw stripping or bone thread damage from over-tightening while ensuring fixation stability.
