The Distal Lateral Humerus Locking Plate is designed to provide stable fixation for fractures of the distal humerus, particularly lateral column fractures.
It features anatomically contoured design with a low-profile structure and multiple locking screw options to achieve angular stability.
The 20° conical threaded holes work synergistically with locking screws to form a fixed-angle construct that enhances stability in osteoporotic and comminuted fractures.
The implant is manufactured from high-quality TA3G pure titanium or TC4 titanium alloy for optimal strength and biocompatibility.
20° conical locking holes compatible with locking compression screws
Sharp self-tapping thread design on screws for easier insertion
Anatomically pre-shaped low-profile plate with rounded edges to reduce soft tissue irritation
Surface anodization for enhanced corrosion resistance and implant identification
Cortex screw heads with spherical design to provide effective axial compression when inserted eccentrically
Screws available in various diameters (Ø1.5 mm to Ø7.3 mm) with appropriate thread depth for cortical or cancellous bone applications
● Fixed-angle stability enhances fixation in osteoporotic bone and complex fracture patterns
● Reduced need for bone-to-plate compression preserves periosteal blood supply and promotes healing
● Smooth polished surface and contoured design minimize soft tissue damage
● Self-tapping screws reduce operative time and improve surgical workflow
● Wide angular coverage allows optimal screw positioning for secure fixation
● Strong thread design increases the bone-screw interface area, ensuring long-term stability
